1300*2500 150W Cnc Clothes Acrylic Laser Cutting Engraving Machine

FOB Reference Price:Get Latest Price
US $4,500-6,000 / Sets | 1 Set/Sets (Min. Order)
Model Number:
LC1325D
Report Suspicious Activity
Overview
Quick Details
Application:
Laser Cutting
Applicable Material:
Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood, 150W Cnc Clothes Acrylic Laser Cutting Engraving Machine
Laser Type:
CO2
Cutting Area:
1300*2500mm
Cutting Speed:
0-24,000mm/min
Graphic Format Supported:
AI, BMP, DST, DXF, PLT, 150W Cnc Clothes Acrylic Laser Cutting Engraving Machine
Condition:
New
Cutting Thickness:
<30mm
CNC or Not:
Yes
Cooling Mode:
Water Cooling
Control Software:
DSP Control System
Place of Origin:
Shandong, China (Mainland)
Brand Name:
Gweike
Certification:
CE, ISO, FDA
After-sales Service Provided:
Online support, Free spare parts, Video technical support
Warranty:
1 YEAR
Driving System:
Stepper
Control System:
DSP control system
Color:
As your request
Cooling System:
CW5000
Whole machine size:
3500*2000*990mm
Product name:
Laser Engraving Cutting Machine
Laser source:
CO2
Working table:
Sawtooth Platform
Laser power:
60/80/100/130/150w
Supply Ability
Supply Ability:
3000 Set/Sets per Year 150W Cnc Clothes Acrylic Laser Cutting Engraving Machine
Packaging & Delivery
Packaging Details
Wooden Package
Port
Qingdao/Ningbo/Dalian/Guangzhou/Shanghai
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(day) 7 To be negotiated
1300*2500 150W Cnc Clothes Acrylic  Laser Cutting Engraving Machine
Product Description



Key point:

Please kindly tell me your cutting materials, and materials’ size.

Then we can quickly check and recommend the most suitable machine for you!

LC1325D-1Laser-Cutting-Machine-(2)1325D

Parameters

Working area1300mm*2500mm
X axis1300mm
Y axis2500mm
Z axis40mm
X.Y positioning accuracy
≤±0.05mm
X.Y resetting positioning accuracy ≤±0.01mm
X.Y max positioning speed0-24,000mm/min
Laser power80W,100w,130w,150w,200w(optional)
Cooling systemCW5000
Cutting object precision ±0.05mm/1000mm(steel)
Cutting material thicknesssteel<1.5mm;stainless steel<1.5mm;arcylic<30mm
Whole machine size3500*2000*990mm
ControllerLeetro
Weight800Kg
Power4KW
Voltage220V
Hertz50HZ



Configuring Content

150W glass CO2 tube
Stepper
Taiwan imports of ball screw
Taiwan imported linear guide rail
Capacitance automatic block
Professional constant temperature cooling system
High power exhaust system
Precision machining welding lathe bed
American import auto focus lens and reflect mirror



Optional Content

Red dot location
Auto focus
Rotary
Alarm



Machine Picture



Laser head

LC1325D





1325d1 laser



Professional constant temperature cooling system

chiller



1300*2500 150W Cnc Clothes Acrylic  Laser Cutting Engraving Machine



Applicable materials



LC1325D is a mixing cutting machine,specialized in cutting stainless steel,carbon

steel,MDF and arcylic.

High efficicy:The cutting speed of 1mm stainless steel is 1800mm/min,

20mm arcylic with perfect cutting quality.

LC1325D machine is matched with the Panasonic servo system and high precision.

Ball-screw system to ensure the high precision,running stable and long-operation.

Low running cost about 5KVA/hour.

This type of laser cutting machine is thermal deformation ,high precision,

low noise,no pollution,easy to do auto cutting.



Sample Picture

 nometal (2)nometal







acrylic cutting samples



 1300*2500 150W Cnc Clothes Acrylic  Laser Cutting Engraving Machine



Company Information



  Jinan Gweike Laser was established in July 2004,its is the largest fiber laser cutting machine, engraving machine and marking machine manufacturer in the noeth of chinaproduct are sold in more than 90 countries.

  We have our own 3 factories, sheet metal production, machine production and assembly, spray workshopfor perfect guarantee the quality of the machine and the time of delivery



CUSTOMER SUPPORTfiber laser cutting machine-company profile (4)
 customer (6)
Packaging & Shipping



1325 150W Cnc Clothes Acrylic  Laser Cutting Engraving Machine



1.Anti-collision package edge: All parts of the machine are covered with some soft materials, mainly the use of pearl wool

2.Fumigation wooden box

3.Whole film packaging machine

4.Wooden box at the bottom of a solid iron socket for easy handling

Quality control in pacakage-laser cutting machineQuality control in inspection-laser cutting machine

Our Services

1325D 150W Cnc Clothes Acrylic  Laser Cutting Engraving Machine

 Warranty



One year for machine,and 10 months for laser tube.

We supply online service 24 hours a day,you can contact me with msn ,qq,or by phone urgently





FAQ



Please advise us the follow questions,so that we can recommended you the most suitable modle,Right now,contact us!!!

1,Are you interested in laser cutting machine or laser engraver?
2,What materials do you need to engrave or cut?
3,Is that material in  roll or in sheet?what is the width?
4,After engraved/cut,what will be the material used for?
5,Are you a end-user or reseller?


How to contact us?
Send your inquiry details in the below for free sample,click "send" now!!!
